1P-77519-C
Plate assy (trans. clutch)-internal spline-use
in front clutch
1L-77521-A
Pin (trans. rear band actuating lever)-3/8" dia.
x 1-3/4" long clevis
72009-S Cotter pin-3/32" x 5/8"
1P-77522-A
Plate (transmission rear clutch pressure)
1P-77523-A
Snap ring (trans. rear clutch plate retainer)-
5-9/16" O. D. x . 076" thick
B5S-77524-A
Washer (trans. rear clutch sun gear counter
thrust)- FFPMB-77524-A
B5S-77525-A
Washer (trans. rear clutch sun gear thrust)-
cPMB-77525-A
8L-77530
Washer (trans. front clutch drum rear backing)-
Steel-1-3/8" I.D. x 1-15/16" O.D. x 3/32" thick
B5S-77530-A
Gear assy (trans. front clutch) -®PMB-77530-A
353078-S
Ball (steel)-1/4" dia.
8L-77531
Piston (transmission front clutch cylinder)
8L-77532
Drum assembly (transmission front clutch)
8L-77535
Kit (trans. clutch piston seal and expander)-
consists of the following
(1)
Expander (piston oil seal)-inner
(1)
Expander (piston oil seal)-outer
(1)
Seal (piston)-2-7/8" diameter
(1)
Seal (piston)-5-1/8" diameter
8L-77536
Drum and pin assembly (transmission front)
OL-77540
Piston (trans. front band release)-1-1/8"
overall length
B5S-77542-A
Oil seal (trans. front clutch sun gear)-front-
EBPMB-77542-A
OL-77543
Cylinder (transmission front band release)
-has (2) flanges with 9/32" dia. drilled hole
LA-77543-A
Cylinder (transmission front band release)
-has (2) flanges with 9/32" dia. drilled hole &
(1) blank flange
