LA-77436-A
Spring (transmission rear servo exhaust valve)
-15/64" 0. D. x 1-1/64" free length x 18 coils
LA-77436-B
Spring (transmission rear servo exhaust valve)
-15/64" 0. D. x 61/64" free length x 19 coils
LA-77437-A
Spring (trans. rear band release)-21/64" 0. D.
x approx. 1-7/64" free length
LA-77437-B
Spring (transmission rear band release)
8L-77438
Ring (oil seal)-2-3/8" x 3/32"-trans. rear servo
accumulator
B5A-77440-A
Regulator assy (transmission oil pressure)-
(DPMB-77440-A
357235-S
Bolt (hex-hd)-5/16"-18 x 7/8"-regulator to
transmission case
34806-S7
Lockwasher-5/16"-regulator to trans. case
358502-S
Screw & L/Washer assy (fill-hd)-No. 10-24 x
3/4"-attaches cover to body
LA-77441-A
Valve (transmission line exhaust)
-1-37/64" overall length
LA-77441-B
Valve (transmission line exhaust)
-1" overall length
LA-77441-C
Valve (transmission line exhaust)
-1-13/64" overall length
1L-77444-A
Body assembly (transmission rear servo)
LA-77446-A
Body (transmission rear servo)
LA-77446-B
Body (transmission rear servo)
20228-S8
Bolt (hex-hd)-3/8"-16 x 2"-rear servo to case
34807-S8
Lockwasher-3/8"
