r
B5S-77468-A
Tube (trans. compensator pressure oil)-
EPMB-77468-A
8L-77469
Plunger (trans. rear servo check valve)
-3/8" O. D. large end x 3/8" overall length
LA-77469-A
Plunger (trans. rear servo check valve)
-31/64" O. D. large end x 3/8" overall length
B5S-77469-A
Tube (trans. main oil pressure) - BPMB-77469-A
8L-77470
Piston and stem assy (trans. rear servo booster)
B5A-77470-A
Tube (trans. lubricating oil)-EDPMB-77470-A
LA-77471-A
Spring (transmission line exhaust valve)
LA-77472-A
Pan assembly (transmission oil)
20310-S8
Bolt (hex head)-5/16"-18 x 1/2"-oil pan to
transmission case
34941-S7
Lockwasher (external tooth)-5/16"
B5S-77472-B
Pan assy (trans. oil)-DPMB-77472-B
20326-S7
Bolt (hex-hd)-5/16"-18 x 5/8"-oil pan to
transmission case
34806-S7
Lockwasher-5/16" -oil pan to trans. case
1L-77475-A
Piston (trans. rear servo compensator)-
serviced in HAK-77475-A Kit
HAK-77475-A
Kit (trans. rear servo compensator piston and
spring)-consists of the following
(1) 1L-77455-A
Spring
(1) 1L-77475-A
Piston
LA-77480-A
Gasket (trans. front servo body)-also serviced
in HAK-7086-B Kit
B5A-77482-A
Clip (trans. oil pan screen retaining)-
EBPMB-77482-A
8L-77483
Plug and gasket assy (trans. oil pan drain)
8L-77485
Gasket (transmission oil pan drain plug)-
-also serviced in HAK-7086-B Kit
B5S-77486-B
Gasket (trans. oil pan)-®PMB-77486-B
B5S-77488-A
Screen assy (trans. oil pan)-®PMB-77488-A
B5A-77502-B
Drum & sun gear assy (trans. front brake)-®
PMB-77502-A
8L-77510
Band assembly (transmission front)-riveted
LA-77510-A
Band assembly (transmission front)-Bonded
B5A-77512-A
"0" Ring (trans. rear clutch piston oil)-inner
Synthetic Rubber -@PMB- 77512-A
1P-77512-A
"0" Ring (trans. front clutch piston oil)-inner-
Rubber-1-43/64" O. D. x 1-27/64" I. D. x
1/8" thick
1P-77513-A
Oil seal (trans. rear clutch piston)-outer-
Rubber-5-1/4" O. D. x 4-3/4" I. D. x 1/8" thk.
PMC-77514-A
Piston (transmission rear clutch)
8L-77515
Stop (transmission band anchor)
33943-S8
Nut (hex)-1/2"-20-trans. band anchor stop
1P-77515-B
Spring (trans. rear clutch piston)-left hand coils
8L-77516
Lever (transmission rear band actuating)
B5A-77516-B
Seat (trans. rear clutch piston spring)-(D
PMB-77516-B
B5A-77517-A
Snap ring (trans. rear clutch piston spring
retainer)- TPMB-77 517 -A
8L-77518
Band assy (trans. rear)-with band rivets
LA-77518-A
Band assy (trans. rear)-without band rivets
1P-77518-A
Plate (trans. rear clutch)-external spline
1P-77519-A
Plate assy (trans. clutch)-internal spline-use
in rear clutch
