LA-77447-A
Sleeve (trans. line exhaust valve)-13/321, O. D. x
1-25/32" long
8L-77448
Kit (trans. rear servo check valve)-consists of
the following
(1)
Rivet (flat head)
(1)
Valve (rear servo check)
LA-77448-A
Kit (trans. rear servo check valve)-consists of
the following
(1)
Rivet (flat head)
(1) LA-77449-A Valve (rear servo check)
LA-77448-B
Kit (trans. rear servo check valve)-consists of
the following
(1)
Rivet (flat head)- 1/8" x 3/8"
(1) LA-77449-B Valve (rear servo check)
LA-77449-A
Valve (trans. rear servo check)-serviced in
LA-77448-A Kit
LA-77449-B
Valve (trans. rear servo check)-serviced in
LA-77448-B Kit
8L-77450
Spring (trans. rear servo pressure)-5/8" O. D.
x 1-15/64" freejength
8L-77452
Retainer (transmission rear servo spring)
20220-S Bolt (hex head)-5/16"-18 x 2"-rear spring
retainer to body
34806-57
Lockwasher-5/161,
B5A-77452-A
Cover (trans. oil pressure regulator body)-
cFPMB-77452-A
8L-77453
Spring (trans. rear servo compression)-1-29/32"
O. D. x 4-1/4" free length
1L-77454-A
Body assembly (trans. rear servo accumulator)
LA-77454-A
Body assembly (trans. rear servo accumulator)-
with yellow dye marking on accumulator body
LA-77454-B
Body assembly (rear servo accumulator)
1L-77455-A
Spring (trans. rear servo)-1-5/64" O. D. x
3-59/64" free length-serviced in HAK-77475-A
Kit
1P-77455-A
Spring (trans. front pump check valve)-13/32"
O. D. x 5/8" o/all free length-5 coils
LA-77457-A
Gasket (transmission rear servo)-also serviced
in HAK-7086-B Kit
8L-77459
Spring (trans. rear servo booster)-6-1/4" coils
-1-5/16" O. D. x 1-17/32" free length
8L-77460
Piston and stem assembly (trans. rear servo
accumulator
B5A-77460-A
Plate (trans. oil pressure reg. body separating)-
®PMB-77460-A
B5A-77462-A
Retainer (trans. main oil pressure reg. valve)-
®PMB-77462-A
B5A-77463-B
Spring (trans. main oil pressure regulator valve)
-®PMB-77463-A
8L-77465
Spring (transmission rear servo outer)
B5A-77465-B
Spring (trans. low oil pressure regulator valve)
Green- ®PMB-77465-B
B5A-77466-A
Seat (trans. oil pressure reg. valve spring)-
®PMB-77466-A
1L-77467-A
Tube (trans. pressure regulator reverse oil)
-"J" uniformly shaped
LA-77467-A
Tube (trans. pressure regulator reverse oil)
-"J" irregularly shaped
LA-77467-B
Tube (trans. pressure regulator reverse oil)
LA-77468-A
Pipe (rear servo compensator)
