358509-S
Screw (fillister head)-No. 10-24 x 7/16"
357846-S
Screw (flat-hd)-No. 10-24 x 3/8"-control end
body plate to control end body
1L-77745-A
Valve (trans. throttle pressure oil regulator)-
5/16" minimum 0. D. x 1" long-serviced in
HBK-77383-A Kit
B5A-77749-A
Plate (transmission control upper valve body)-
®PMB-77749-A
B5A-77761-A
Spring (transmission throttle valve return)-
PMB-77761-A
1P-77763-B
Plate (trans. control upper valve body)-front
B5A-77764-A
Valve (trans. control manual)-®PMB-77764-A
LA-77768-A
Spring (trans. throttle valve regulator)-use with
LA-9747-H, LA-77230-E & LA-77242-D
8L-77769
Kit (trans. manual control shaft seal and washer)-
consists of the following
(1)
Seal (manual shaft)
(1)
Washer (manual shaft seal)-inner
(1)
Washer (manual shaft seal)-outer
LE-77772-A
Brace (transmission control linkage splash pan)
20327-S8
Bolt (hex-hd)-5/16"-24 x 5/8"-brace to pan
& intake duct
34806-S7
Lockwasher-5/16" -use with 20327-S8
33798-S8
Nut (hex)-5/16"-24-use with 20327-S8
B5S-77820-A
Pump assy (trans. oil) -front-®PMB-77820-A
357911-S
Bolt (hex-hd)-5/16"-18 x 2"-front pump to
case
1P-77836-A
Gasket (trans. front oil pump)-Cork & Rubber
composition-5-17/32" I. D. x 5-29/32" 0. D.
x 1/8" thick
