B5S-77548-A
Washer (trans. front clutch sun thrust)-rear-
Bronze-®PMB-77548-A
8L-77551
Plate (transmission clutch driven)
B5A-77556-A
Cylinder (trans. front clutch)- TPMB-77556-A
1P-77558-A
Oil seal (trans. front clutch piston)-outer-Rubber-
3-7/8" I. D. x 4-13/32" O. D. x 1/8" thick
B5A-77562-A
Piston (trans. front clutch)- Aluminum -(D
PMB-77562-A
8L-77563
Plate assembly (transmission clutch drive)
1P-77563-A
Ring (trans. front clutch piston spring pressure)-
spring wire-2-13/16" I. D. x 3-1/16" O. D.
x 1/8" thick
1P-77565-A
Spring (transmission front clutch piston disc)-
5-5/16" O. D. x 5/64" thick -cupped
1P-77567-A
Snap ring (transmission front clutch cylinder)-
5-19/32" O. D. x 3/32" thick
1P-77569-A
Plate (trans. front clutch pressure)-Cast Iron
8L-77572
Piston (transmission rear clutch cylinder)
-with (3) "U" shaped slots on outside diameter
LA-77572-A
Piston (transmission rear clutch cylinder)
-with (6) "U" shaped slots on outside diameter
1L-77573-A
Drum and pin assembly (transmission rear)
LA-77573-A
Drum and pin assembly (transmission rear)
1P-77573-A
Plate (trans. front clutch external spline)
B5S-77574-A
Hub (trans. front clutch)-PMB-77574-A
8L-77575
Pin (transmission rear clutch spring guide)-
.116"/. 122" diameter x 1-5/8" long
B5S-77577-B
Washer (trans. front clutch hub thrust)-
Laminated Phenolic-®PMB-77577-B
8L-77578
Spring (transmission clutch release)-inner-
15/64" O. D. x 2-15/64" free length
8L-77579-A
Hub (transmission rear clutch) -replaced by
HEK-77579-A Kit
LA-77579-A
Hub (transmission rear clutch)
LA-77579-B
Hub (trans. rear clutch)-serviced in
HEK-77579-A Kit
HEK-77579-A
Kit (trans. hub & washer rear clutch)- consists
of the following
(1) 8L-77579-B Hub
(1) 8L-77581-B Washer
8L-77581-A
Washer (transmission rear clutch hub thrust)-
Bronze-Grooved-2-7/8" O. D. x 1-15/16" I. D.
x .087"/.091" thick
8L-77581-B
Washer (trans. rear clutch hub thrust)-use
with 8L-77579-B-also serviced in HEK-77579-A
8L-77582
Spring (transmission clutch release)-outer-
3/8" O. D. x 2-31/64" free length
8L-77584
Snap ring (transmission rear clutch cyl. ret. )-
6-3/8" O. D. x 5-7/8" I. D. x 3/32" thick
1L-77590-A
Washer (transmission reverse clutch release
spring retainer)-with (2) flanges 3-7/8" O. D.
x 3-1/16" I. D.
LA-77590-A
Washer (transmission reverse clutch reverse
spring retainer)
