1P-77420-A
Bolt (hex-hd)-7/16"-14 x 2-15/32"-with pilot end-
transmission rear band servo to case
1P-77421-A
Strut (trans. rear band actuating)-29/32" wide
x 1-7/64" long x .169" thick
1P-77422-B
Strut (trans. rear band anchor)-9/16" & 1-1/4"
wide x 1-7/32" long, tapered
B5S-77423-A
Band assy (transmission rear) -®PMB-77423-A
8L-77424
Spring (trans. front servo retracting)-13/16" O. D.
x approximately 1-33/64" free length
LA-77424-A
Spring (trans. front servo retracting)- 1-33/64"
long-free length-use only with LA-77410-A
LA-77424-B
Spring (trans. front servo retracting)-1-29/32"
long-free length
8L-77425
Spring (trans. front servo booster)-1-11/32" O. D.
x approximately 61/64" free length
LA-77425-A
Spring (transmission front servo booster)
8L-77426
Pipe (trans. servo oil transfer)-1-3/16" long
B5A-77426-A
Stop (trans. rear band adjusting)-1/2"-20 x
2-7/16" o/all length-®PAG-77426-A
358514-S
Nut (hex-jam)-1/2"-16-to lock rear band
adjusting stop to transmission case
LA-77427-A
Valve (trans. rear servo exhaust)-7/16" O. D. x
55/64" long
LA-77427-B
Valve (trans. rear servo exhaust manual low oil)
8L-77428-B
Ring (oil seal)-1-3/16' x 3/32"-trans. governor
8L-77429-B
Ring (oil seal)-1-1/4" x 3/32"-trans. rear servo
compensator piston
8L-77430
Ring (oil seal)- 1-5/16" x 3/32"-trans. front band
apply piston
LA-77430-A
Ring (oil seal)-1-7/16" x 3/32"-trans. front band
apply piston
8L-77431
Ring (oil seal)-1-5/8" x 3/32"-trans. front band
release piston
8L-77432-B
Ring (oil seal)-2" x 3/32"-trans. oil delivery
sleeve
