 HCK HEK HEK 8L 91A 96H 96H 96HOM 8M LALA LALA   LALALALA LA
2200-B
Kit (rear brake shoe 8i lining) -. 030 0/S-Axle Set-
consists of the following
(2) LA-2218-C Shoe & lining-rear-primary
(2) MA-2019-C Shoe & lining-rear-secondary
1
LA
52-53
2200-A
Kit (rear brake shoe & lining)-Standard-Axle Set-
consists of the following
(2) LA-2218-E Shoe & lining-rear-primary
12) LA-2219-C Shoe & lining-rear-secondary
1
LA
LE
54-55
2200-B
Kit (rear brake shoe & lining)-. 030 0/S-Axle Set-
consists of the following
(2) LA-2218-F Shoe & lining-rear-primary
(2) LA-2219-D Shoe & lining-rear-secondary
1
LA
LE
54-55
2201
Cup (rear wheel brake cylinder)-15/16" dia. -also
serviced in 8L-2128 Kit
4
LA
LE
52-55
2202
Cup (front wheel brake cylinder)-1-1/$' dia. -also
serviced in 8M-2221 Kit
4
LA
LE
52-55
2204
Spring (rear wheel brake cylinder piston return)-
9/16" 0. D. x 2-5/16" o/all free length-11 coils
2
LA
LE
52-55
2205
Spring (front wheel brake cylinder piston return)-
11/16" 0. D. x 2-1/4" o/all free length-9-1/2
coils
2
LA
LE
52-55
2206
Boot (brake wheel cylinder)-rear-also serviced
in 8L-2128 Kit
4
LA
LE
52-55
2207-A
Boot wheel cylinder)-front-also serviced
(brake in 8M-2221 Kit
4
LA,
LE
52-55
2208
Screw (brake wheel cylinder bleeder)-3/8"-24 x
1-3/16" overall length
4
LA
LE
52-55
2211-A
Plate assembly rear wheel brake backing }-R. H.
1
LA
52-53
2211-B
Plate assembly (rear wheel brake backing)-R. H.
1
LA,
LE
54-55
2212-A
Plate assembly (rear wheel brake backing)-L. H.
1
LA
52-53
2212-B
Plate assembly (rear wheel brake backing)-L. H.
1
LA,
LE
54-55
8M-2248 Bolt (rear axle brake housing)-
1/2"-20 x 1-1/8" special head
8
LA
LE
52-55
34424-S7 Locknut (hex)-1/2"-20
8
LA,
LE
52-55
2218-B
Shoe d~ lining (rear)-primary-std. -serviced in
HCK-2200-A Kit
2
LA
52-53
2218-C
Shoe & lining (rear)-primary-. 030" 0/S-serviced
HCK-2200-B Kit
2
LA
52-53
2218-E
Shoe & lining (rear)-primary-std. -serviced in
HEK-2200-A Kit
2
LA,
LE
54-55
2218-F N
Shoe & lining (rear)-primary-. 030" 0/S-serviced
in HEK-2200-B Kit
2
LA,
LE
54-55
2219-C N
Shoe & lining (rear)-secondary-std. -serviced in
HEK-2200-A Kit
2
LA
LE
54-55
