_ I Tube assy (rear brake}-11-63/64
LA 2267-A
Tube assy (rear brake)-41-9/32" approx, overall
1
LA
52-53
length-R. H.
LA 2267-B
Tube assy (rear brake)-41" approx. overall length
1
LA
54
LE 2267-A
Tube assy (rear brake}-36-1/2" approx. overall
1
LE
55
length
358349-S32
Clip (rear brake right pipe)-
1
LA, LE
52-55
fastened to rear axle diff.
housing
34807-58
Lockwasher-3/8"-used with
1
LA, LE
52-55
20328-57
87942-58
Nut (tube fitting)-3/8"-24-
10
LA, LE
52-55
brake pipe attaching nut
31527-57
Screw (hex washer head self
1
LA LE
52-55
tapping}-No.14-14 x 1/2"
used with 8M-2244
LA 2268-A
Tube assy (rear brake)-12-17/64" approx. overall
1
LA
52-53
length-L. H.
LA 2268-B
1
LA
54
LE 2268 A
Tube assy ( rear brake ) 18' a pp rox. overall length
1
LE
55
-L. H.
LA 2275-B I
Cable & conduit assy (hand brake)-rear-139-3/8"
1
LA, LE
52-55
long
8M-2814
Clip (hand brake cable spring
2
LA, LE
52-55
lock)
8L 2276
Bolt (rear brake cylinder connection)-1f 2"-20 x
1
LA, LE
52-55
1-1/8" and 1/8"-27 female thread-with 13/32"
dia. hole thru head-for attaching brake master
cylinder outlet fitting
91T 2276
Bolt (master cylinder outlet}-1/2"-20 x 1-1/8"-
1
LA, LE
53-55
to attach master cylinder outlet fitting
91A-2279
Clip (reservoir to booster)-(2) 25 64" dia. holes
2
LA, LE
53-55
LE 2282-A
Hose assy (rear wheel brake}
1
LE
55
LA 2284-B N
Rear brake lining (primary}-std. -serviced in
2
LA
52-53
HCK-2222-A Kit
LA 2284-C N
Rear brake lining (primary)-. 030 0/S-serviced in
2
LA
52-53
HCK-2222-B Kit
LA 2284-F N
Rear brake lining (primary}-std. -serviced in
2
LA, LE
54-55
HEK-2222-A Kit
LA 2284-G N
Rear brake lining (primary)-. 030 0/S-serviced in
2
LA. LE
54-55
HEK-2222-H Kit
LA 2285-C N
Rear brake lining (secondary)-std. -serviced in
2
LA, LE
54-55
HEK-2222-A Kit
