NS 59T-2348
Wick (brake vacuum booster
piston)-Yarn- serviced in
HDK-22167-B & HEK-22167-A
Kits
LA, LE
53-55
NS LA-2356-A
Packing (brake booster body
piston)-6" diameter-serviced
in HDK-22167-B and
HEK-22167-A Kits
LA, LE
53-55
NS LA-2357-A
Ring (brake booster body piston
packing)-serviced in
HDK-22167-B & HEK-22167-A
Kits
LA, LE
53-55
LA-2361-A
Spring (brake booster body
piston return) -4- 1/4" dia.
at
large end
LA, LE
53-55
LA-2366-A
Body asst' (brake booster)
LA, LE
53-55
NS LA-2384-A
Seal (brake booster push rod)-
21/32" I. D. x 1-3/8" O. D. -
serviced in HDK-22160-B Kit
LA, LE
53-55
LA-2388-A
Bearing assy (brake master cyl.
push rod end)-1-1/4" full
thread
LA, LE
53-55
33800-S8
Nut (hex)-3/8"-24
LA, LE
53-55
LA-2394-A
Retainer (brake booster body
piston packing)
LA, LE
53-55
LA-2395-C
Piston assy (brake booster body)
LA, LE
53-55
352525-S8
Screw (fillister head)-No. 8-32
x 3/8"
LA, LE
53-55
LA-2429-A
Retainer (brake booster piston
felt)
LA, LE
53-55
33800-S8
Nut (hex)-3/8"-24
LA, LE
53-55
352525-S8
Screw (fillister head)-No. 8-32
x 3/8"
LA, LE
53-55
NS 59T-2437
Seal (brake vacuum booster slave
cylinder end body)-55/64" I. D.
x 1-1/64" O. D. -serviced in
HDK-22160-B Kit
LA, LE
53-55
NS LA-2440-A
Collar (brake booster push rod)-
serviced in HDK-22160-B Kit
LA, LE
53-55
$MA-2454-H
Pad assy (brake pedal)
LA, LE
54-55
LA-2455-G
Pedal assy (brake)-includes lever
LA
54
LE-2455-A
Pedal assy (brake)
1
LE
55
34671-S8
Nut (hex)-7/16"-20
1
LA, LE
54-55
352602-S8
Pin (clevis)-3/8" x 1-1/16"-
operating lever to lever assy
LA, LE
53-55
352602-S8
Pin (clevis)-3/8" x 1-1/16"-
operating lever to pedal
assy
LA, LE
53-55
72035-S7-8
Pin (cotter)-1/8" x 1"-
operating lever to brake
pedal
LA, LE
53-55
72035-S7-8
Pin (cotter)-1/8" x 1"-
operating lever to lever assy
LA, LE
53-55
# Use with Power Brake & Standard
Brakes
