_ L~~__ 0. D. x 59/64
8A 2456-B
Spring (brake pedal retracting)-8„ free length-
34 coils
LA, LE
52-55
AB 2461-B
Bushing (brake pedal)-Nylon-5/8" I. D. x 11/16"
0. D. x 1-59/64" long-use with Power Brakes
1953 & 1954 only
1
LA, LE
52-55
LE 2461-A
Bushing (brake pedal)-Nylon-5/8" I. D. x 11/16"
1
LE
55
AB 2462-A
Bolt (master cylinder link rod eccentric)-3/8"-24
x 1-3/16"
1
LA, LE
52-55
34420-58 Locknut (hex)-3/8"-24
1
LA, LE
52-55
LA 2466-A
Link (brake pedal lever to master cylinder
operating lever)-with (2) 3/8" dia. holes
2
LA
53-54
LE 2466-A
Link (brake pedal lever to master cylinder operating
lever)
2
LE
55
AB 2472-C
Spring (brake pedal retracting)
1
LA
52
AB 2472-D
Spring (brake pedal retracting)
1
LA, LE
53-55
B2A 2474-A
Bushing (brake master cylinder push rod)-Nylon-
CAB-22473-A
1
LA, LE
52-55
AB 2478-A
Shaft (brake pedal)-7 16"-20 x 3"
1
LA, LE
52-55
34808-SS Lockwasher-7/16"
1
LA,LE
52-55
33802-58 Nut (hex)-7/16"-20-shaft to
brake support & brace
1
LA, LE
52-55
B2A 2481-A
Insulator (brake pedal hub spring)-Paper-
AMA- 22482-A
1
LA
52
B2A 2481-B
Insulator (brake pedal hub spring)-Nylon-
CAB- 22482-A
1
LA, LE
53-55
LA 2482-A
Shaft (brake master cylinder operating lever)-3/8"
-24 x 2-17/32" long
1
LA
53
LA 2482-B
Shaft (brake master cylinder operating lever)-3/8"
-24 x 2-11/32" long
1
LA
54
LE 2482-A
Shaft (brake master cylinder operating lever}-3/8"
-24 x 2-11/32" long
1
LE
55
X351022-52 Locknut (hex)-3/8"-24-retain
operating lever in lever
bracket
1
LA
53-54
TFAF 2493
Gasket (brake booster end plate)-1-11/32" I. D.
x 1-19/32" 0. D. -serviced in HDK-22160-B Kit
1
LA. LE
53-55
LA 2514-A
Lever assy (brake master cylinder operating)
1
LA
53
LA 2514-B
Lever ass brake master cylinder operating)
1
LA
54
LE 2514-A
Lever assy (brake master cylinder operating)
1
LE
55
OM 2529
Rod (hand brake equalizer)-5-23/32" overall
length-with one end bent at right angle to
threaded diameter
1
LA, LE
52-55
33798-S8 Nut (hex)-5/16"-24
2
LA, LE
52-55
351640-S32 Nut (spring}-9/32" diameter
1
LA, LE
52-55
LA 2530-A
Bracket (hand brake cable)-rear-R. H.
1
LA, LE
52-55
LA 2531-A
Bracket (hand brake cable)-rear-L. H.
1
LA, LE
52-55
LA 2532-A
Lever (hand brake equalizer)
1
LA, LE
52-55
8A-2091 Nut (hand brake equalizer lever)-
5/16"-24-equalizer lever to
front cable assy
1
LA, LE
52-55
8A-2456-B Spring (hand brake equalizer
lever retracting)-8" free
length-34 coils
1
LA, LE
52-55
