 LE  8MLE       LA    AB  LA    LA      LA         LA   8A   H 8A   MA 8L    MA SL   91A   MA
2073-A
Bracket (rear wheel brake hose)
1
LE
55
2074
Connector (rear brake line)-has (3) 3/8"-24 tapped
holes
1
LA
52-54
2074-A
Connector (rear wheel brake tube)
1
LE
55
24389-S8 Bolt (hex hd)-3/8"-24 x 1"
1
LA,
LE
52-55
34807-S8 Lockwasher-3/8"
1
LA,
LE
52-55
2075-A
Connector asst' (front brake line)-has (4) 3/8"-24
tapped holes
1
LA,
LE
52-55
40923-52 Screw (hex washer hd)-5/16"-
18 x 1/2"-connector to frame
1
LA,
LE
52-55
2076-A
Fitting (brake master c I. outlet)-has (1) hole
1
LA,
LE
52-55
2076-A
Fitting (brake master cyl. outlet)-has (2) holes
1
LA, LE
53-55
8L-2276 Bolt (brake master cylinder outlet
connection)-1/2"-20 x 1-5/8"
overall length
1
LA,
LE
52-55
2078-A
Hose asst' (rear brake)-18-27 32" overall length
1
LA
52-54
8M-2149 Gasket ( rear brake line connector
-Copper-25/64" I. D. x 5/8"
0. D. x 1/16" thick
1
LA LE
52-55
78-2814-A Clip (rear brake hose to frame
and bracket)
1
LA
52-54
2079-A
Hose asst' (front brake)-15-3/32" overall length
2
LA,
LE
52-55
8M-2149 Gasket (front brake hose asst' to
brake cyl. }-25/64" I. D. x 5/8"
0. D. x 1/16" thick
2
LA, LE
52-55
78-2814-A Clip (front brake hose to bracket}
2
LA
52-54
2082-A
Bracket (brake hose front)
2
LA, LE
52-55
2091
Nut (hand brake equalizer lever)-5/16"-24-
equalizer lever to front cable assembly
1
LA, LE
52-55
2092
Cover (brake adjusting hole)-also serviced in
HCK-22009-B & C & HEK-22009-A Kits
alternate with 8A _ 2092
4
LA, LE
52-55
2092
Cover (brake adjusting hole) also serviced in
HCK-22009-B & C 8i HEK-22009-A Rits
alternate with H-2092
4
LA LE
52-55
2103-A
Lever assembly (parking brake operating)-R. H.
1
LA
52-53
2103
Lever assembly (parking brake operating)-R. H.
1
LA,
LE
54-55
2104-A
Lever assembly (parking brake operating}-L. H.
1
LA
52-53
2104
Lever assembly (parking brake operating)-L. H.
1
LA,
LE
54-55
351467-5 Washer (spring)-3/8"-parking
brake anti rattle
2
LA, LE
52-55
2106
Retainer (rear brake emergency lever pin)
2
LA,
LE
52-55
2108-A
Strut (parking brake}
2
LA
52-53
