HEK 2222-B
Kit (rear brake lining)-. 030 0/S-Axle Set-consists
of the following
(2) LA-2284-G Lining-rear-primary
(2) LA-2285-D Lining-rear-secondary
(44) 351939-S Rivet
1
LA, LE
54-55
8M 2240
Retainer (rear wheel bearing)
2
LA, LE
52-55
8M 2244
Clip (rear brake pipe to rear axle)
1
LA, LE
52-55
8M 2244
Clip (front brake pipe to frame)
1
LA, LE
52-55
31527-S7 Screw (hex washer head self
tap. )-No. 14-14 x 1/2"-to
frame
1
LA, LE
52-55
8M 2245
Gasket (wheel bearing retainer)-Paper
4
LA, LE
52-55
8M 2248
Bolt (rear axle brake housing)-1/2"-20 x 1-1/8"-
special head
8
LA, LE
52-55
34424-S7 Locknut (hex)-1/2"-20
8
LA, LE
52-55
8L 2261-A
I,II Cylinder assy (rear brake)-R. H. -15 16" dia.
1
LA, LE
52-55
8L 2262-A
Cylinder assy (rear brake)-L. H. -15/16- dia.
1
LA, LE
52-55
20310-S8 Bolt (hex-hd)-5/lfi"-18 x 1/2"
4
LA
52-54
34806-S7 Lockwasher-5/16"
4
LA
52-54
8L-2128 Kit (rear wheel brake cyl. repair)
-consists of the following
(2) 8L-2201 Cup (2) 96H-2206 Boot
2
LA, LE
52-55
LA 2263-B
Tube assy (front brake)-R. H. -with 4-13/64" long
curved conduit
1
LA
52-54
LA 2263-C
Tube assy (front brake)-R. H. -with 4-13/64" long
curved conduit
1
LA, LE
54-55
8M__-2244 Clip (front brake pipe to frame)
_
1
LA, LE
52-55
31527-S7 Screw (hex washer head self
tap. )-No. 14-14 x 1/2"-to
frame
1
LA, LE
52-55
LA 2264-B
Tube assembly front brake)-L. H.
1
LA, LE
52-55
MA-22264-C Hose assy (brake master cylinder
to connector) -approx.16-3/4"
long
1
LA
52-54
LA-22264-C Hose assy (brake master cylinder
to connector)-approx. 13-25/3
long
1
LE
55
352223-S32 Clip (hose to front fender
apron)
1
LA, LE
52-55
31527-S7 Screw (hex washer hd self tap-
ping)-No. 14-14 x 1/2"-hose
to front fender apron
1
LA, LE
52-55
LA 2265-B
Tube assy (rear connector to rear hose)-111-27/64'
long
1
LA
52
LA 2265-C
Tube assy (rear brake tube connector to rear hose)
-111-27/64" long
1
LA
53-54
LE 2265-A
Tube assy (rear brake tube connector to rear hose)
1
LE
55
357331-S32 Clip (tube)-3/16"-tube
connector to frame
4
LA, LE
52-55
