in HDK-22167-B 8i HEK-22167-A Kits serviced in HDK-2217-B & HEK-22167-A Kits in HDK-22167-B & HEK-22167-A Kits 0. D. -serviced in HDK-22160-B K it 1-1/4
LA
2285-D N
Rear brake lining (secondary}-, 030 0/S-serviced
in HEK-2222-B Kit
2
LA. LE
54-55
59T
2348
Wick (brake vacuum booster piston)-Yarn-
serviced
1
LA, LE
53-55
LA 2356-A
Packing (brake booster body piston)-6"
diameter
1
LA, LE
53-55
LA
2357-A
Ring (brake booster body piston packing)-
serviced
1
LA, LE
53-55
LA
2361-A
Spring (brake booster body piston return)-4-1/4"
diameter at large end
1
LA, LE
53-55
LA
2366-A
Body assembly (brake booster)
1
LA, LE
53-55
LA
2384-A
Seal (brake booster push rod)-21/32" I. D. x 1-
3/8"
1
LA, LE
53-55
LA
2388-A
Bearing assy (brake master cylinder push rod
end)
1
LA, LE
53-55
LA
2394-A
Retainer (brakes booster body iston packing)
1
LA, LE
53-55
LA
2395-C _
Piston assembly (brake booster body)
1
LA, LE
53-55
LA
2429 A
Retainer (brake booster piston felt)
1
LA, LE
53-55
59T 2437
Seal (brake vacuum booster slave cylinder end)-
55/64" I. D. x 1-1/64" 0. D. -serviced in
HDK-22160-B Kit
1
LA, LE
53-55
LA
2440-A
Collar (brake booster push rod)-serviced in
HDK-22160-B Kit
1
LA, LE
53-55
MA
2454-H
Pad assy (brake pedal)
1
LA, LE
52-55
24427-57 Bolt (hex-hd)-5/16"-24 x
1-1/4"-pad plate to pedal
assy
1
LA, LE
52-55
34443-S7 Locknut (hex}-5/16"-24
1
LA, LE
52-55
LA
2455-D
Pedal assembly (brake)
1
LA
52
LA
2455-F
Pedal assembly (brake)
1
LA
53-54
___
LA
2455-G
Pedal assembly (brake)
1
LA
53-54
LE
2455-A
Pedal assembly (brake)
1
LE
55
MA-7583-A Bumper (brake pedal)-Rubber
1
LA, LE
52-55
f 34671-58 Nut (hex)-7/16"-20
1
LA, LE
54-55
X352602-58 Pin (clevisl-3/8 x 1-1116"-
operating lever to lever assy
1
LA, LE
54-55
352 6 02 - 58 P in (clevis ) - 3/8 x 1 - 1/16 -
operating lever to pedal
assy
1
LA, LE
53-55
172035-57-8 Pin (cotter)-1/8" x 1"-
operating lever to brake
pedal
1
LA, LE
53-55
X72035-5?-8 Pin (cotter)-1/8" x 1"-
operating lever to lever assy
1
LA, LE
53-55
