in HDK-22160-B Kit HDK-22160-B Kit
LA-2005-B
Booster assembly (brake vacuum)
LA
53
LA-2005-C
Booster assembly (brake vacuum)
1
LA
54
LE-2005-A
Booster assembly (brake vacuum)
1
LE
55
20387-S8
Bolt (hex-hd)-5/16"-24 x 1"-
brake power unit to
mounting brkt.
LA, LE
54-55
357624-S7
L/washer (special)-5/16"-
brake power unit to
mounting brkt.
LA, LE
54-55
355960-S
Nut (grommet)-5/16"-24-
brake power unit to
mounting brkt.
LA, LE
54-55
LA-2063-B
Reservoir assy (power brakes)-
vacuum-use with tube
LA-22907-A
LA
53-54
LA-2063-C
Reservoir asst' (power brakes)-
vacuum-use with tube
LA-22907-B-also serviced
in HDK-22005-F Kit
LA
54
LE-2063-A
Reservoir assv (rower brakes)-
vacuum
L
55
40143-S8
Screw (hex-hd)-tapping- 5/16•'-
18 x 1/2"-tank to frame
LA, LE
53-55
LA-2076-A
Fitting (brake master cylinder
outlet)-has (2) holes
LA
53-54
LA-2143-D
Rod assy (brake master cylinder
push)-vacuum booster-7-45/64"
long without groove
LA
52-54
N LA-2152-A
Gasket (brake master cylinder
outlet)-7/8" I. D. -serviced in
HDK-22160-B Kit
LA
53-54
91T-2154-A
Gasket (brake master cylinder
outlet)-Copper-1/2" I. D. x
11/16" O. D. x 1/32" thick
LA
52-54
LA-2155-C
Body (brake master cylinder)
LA
53-54
LA-2161-A
Fitting (brake master cylinder
outlet)-1/2" tapped hole
LA
53-54
91A-2162-A
Cap assy (brake master cylinder
filler)-with square head
LA
53-54
91A-2167
Gasket (brake master cylinder
filler cap)-1-17/64" I. D. x
1-1/2" O. D. -also serviced in
HDK-22160-B Kit
LA
53-54
NS
LA-2178-B
Valve assy (brake master
cylinder outlet check)-serviced
LA
53-54
NS
LA-2180-A
Boot (brake master cylinder
Rubber-serviced in
LA
53-54
LA-2183-A
Spring (brake master cylinder
outlet valve)-15/32" diameter
LA
53-54
91T-2276
Bolt (rear brake cylinder
connection)-1/2"-20x 1-1/8"
LA, LE
53-55
91A-2279
Clip (reservoir to booster)-with
(2) 25/64" dia. holes
LA, LE
_
53-55
