information at time of publication _ overall length serviced in HDR-22160-H Kit
SL 2108
Strut (parking brake}
2
LA, LE
54-55
8M 2119
Equalizer (hand brake cable)
1
LA, LE
52-55
33798-58 Nut (hex)-5/16"-24
2
LA, LE
54-55
LA-22121-A Gasket (brake master cylinder
mounting adapter)
1
LA, LE
52-55
8L 2128
Kit (rear wheel brake cylinder repair)-consists of
the following
(2) 8L-2201 Cup (2) 96H-2206 Boot
2
LA, LE
52-55
8L 2135-A
Housing and tube seat assy (rear brake cylinder)-
R. H.
1
LA, LE
52-55
8L 2136-A
Housing and tube seat assy (rear brake cylinder)-
L. H.
1
LA, LE
52-55
96H 2139-H
Spring (parking brake strut to shoe)-1-1/4" overall
free length, oblong shaped
2
LA, LE
52-55
LE 2140-A
NS Cylinder assy (brake master)-no other details
or
1
LE
55
B2 2140-B
Cylinder assembly (brake master)-less push rod-
®AB-22141-C
1
LA
52-54
LA-22139-A Shield (brake mastercyl. heat)
1
LA, LE
52-55
24387-S7 Bolt (hex head)-5/16"-24 x 1"-
cylinder to firewall
4
LA, LE
52-55
357624-S7 Lockwasher-5/16"-cylinder to
fir ewall
4
LA, LE
52-55
OA-13480 Switch assembly (stop light)
LA, LE
52-55
LA 2143-C
Rod ass Y ( brake master c y linder p ush ) -6-51 /
64f'
1
LA
52-54
33925-57 Nut (hex)-3/8"-24-link to rod
1
LA
52-54
t LA 2143-D
Rod assy (brake master cyl. push)-vacuum booster
1
LA
53-54
B2A 2144-A
Bumper (brake master cylinder push rod)-
A-22144-A
1
LA
52-54
8A 2145
Spring & retainer assy (brake master cyl, return)
1
LA
52-54
8M 2149
Gasket (front & rear brake line connector)-Copper-
25/64" I. D. x 5/8" 0. D. x 1/16" thick
3
LA, LE
52-55
LA 2152-A
N9 Gasket (brake master cylinder outlet)-7/8" I.D.
-
1
LA, LE
53-55
LA 2153-A
Bracket (hand brake cable)-front
1
LA
52-54
LE 2153-A
Bracket (hand brake cable)-front
1
LE
55
91T 2154-A
Gasket (brake master cylinder outlet)-Copper-
1/2"
I. D. x 11/16" 0. D. x 1/32" thick-also serviced
in B2A-2004-A Kit
2
LA, LE
52-55
