HDK-33580-C
Kit (adapter repair)-consists o
the following
(2) LA-33570-B Seal
(4) LA-33580-A Adapter
LA, LE
54-55
LA-33582-B
Spring (power strg. hydraulic
control valve)-43/64" approx.
free length
5
LA, LE
53-55
' LA-33583-A
Cover & guide assy (strg. gear
power rack)
1
LA, LE
53-55
352644-S8
Screw (socket hd)-3/8"-16 x
11/16"-cover and guide to
housing assembly
4
LA, LE
53-55
I
LA-33584-A
Cover (steering gear power rack)
LA, LE
53-55
LA-33585-A
Guide (steering gear power rack)
LA, LE
53-55
352644-S8
Screw (socket hd)-3/8"-16 x
11/16"-power rack cover to
power rack guide
LA, LE
53-55
LA-33586-A
Bearing assy (power strg. gear
worm thrust)
LA, LE
53-55
LA-33587-A
Seal (steering gear sector shaft
grease)-19/16" 0. D. -also
serviced in HDK-33570-A & B
Kits
LA, LE
53-55
LA-33588-A
Hose assy (power steering return
line)-approx. 29-1/2" overall
length
LA
53
LA-33588-B
Hose assy (power steering return
line)-29-1/2" overall length
also serviced in HDK-33588-A
Kit
LA, LE
54-55
351788-S8
Fitting-5/8"-18-to attach hose
to pump and pump to valve
LA, LE
53-55
351789-S
Washer (flat)-41/64"I. D. x
7/8" 0. D. -seal between
fitting and pump assy-also
serviced in HDK-33588-A
Kits
LA, LE
53-55
HDK-33588-A
Kit (hose)-return line-consists o
the following
(1) LA-33588-B Hose (1) 351789-S
Washer
LA, LE
53-55
LA-33592-B
Valve assy (strg. gear hsg. vent)
LA, LE
53-55
353087-S
Bushing (reducing pipe)-to
attach vent to housing assy
1/8" x 1/2" pipe thread
LA, LE
53-55
' LA-33593-A
Washer (strg. gear worm thrust
bearing nut lock)-with 8 tangs
LA, LE
53-55
351698-S
Nut (hex)-l"-16-to adjust
LA-33586-A bearing assy
LA, LE
53-55
LA-33594-A
Shim (steering gear power rack
cover)-. 003" thick-also
serviced in LA-33546-A
as
regd
LA, LE
53-55
