AE-33542-A
Body(power steering oil reservoir
inlet orifice)
LA, LE
54-55
352695-S8
Stud-5/16"-24 to 5/16"-18 x
2-5/8"-attaches cover &
filter to body
LA
53
LA-33546-A
Kit (cylinder & rack assy)-
consists of the following
(1) LA-3565-A Cylinder (2) LA-33594-A
Shim
(1) LA-33594-B Shim
(1) LA-33601-A Gskt.
(4) LA-33606-A Seal
LA
53
LA-33547-A
Ring (power strg. oil reservoir
orifice-"O")-3/4" I. D.
LA, LE
53-55
LA-33549-A
Ring (power strg. oil reservoir
orifice-"O")-5/16" I. D.
LA, LE
53-55
LA-33550-A
Insulator (power steering hose
2-7/8" long
LA, LE
53-55
LA-33551-A
Bearing assy (strg. gear worm -
lower-1-1/8" I. D. x 1-1/2"
O. D.
LA, LE
53-55
LA-33552-A
Retainer (power steering hose
insulator)
LA, LE
53-55
40923-S2
Screw (hex head)-5/16"-18 x
1/2"-hose insulator retainer
to brkt. support to frame
LA, LE
53-55
LA-33553-A
Reinforcement (power steering
oil reservoir orifice)-with (2)
25/32" dia. holes
LA, LE
53-55
B4Q-33554-A
Bracket (power steering pump
adjusting)-BEAD-33554-A
LA. LE
53-55
43012-S Bolt (hex-hd-self locking)-
3/8"-16 x 2-3/4"-bracket
to pump assy
LA, LE
53-55
352115-58
Washer (flat)-25/64"I. D. x
1-1/8" O. D. x 7/64" thick
LA. LE
53-55
EAD-33556-A
Pulley (power steering pump)
LA
53-54
EAD-33556-B
Pulley (power steering pump)
1
LA
54
EBJ-33556-A
Pulley (power steering pump)
1
LE
55
354114-S8
Screw & lockwasher assy (hex
head)-5/16"-18 x 7/8"
pump pulley to pump assy
LA, LE
53-55
353846-S8
Washer (flat)-5/1F"
LA, LE
53-55
EAD-33557-A
Key (power steering pump
pulley)-1/2" long
LA, LE
53-55
EAD-33558-A
Belt (power steering pump pulley)
LA
53-54
EAD-33558-B
Belt (power steering pump pulley)
1
LA
54
EBJ-33558-A
Belt (power steering pump pulley)
1
LE
55
EBJ-33558-B
Belt (power steering pump pulley)
-used with Air C',rr~iti,rirr:
_
LE except 76
55
