LA-33637-A
Hose assy (power strg. hyd. control
valve to power head end)
LA, LE
53-55
8-3/16" approx. formed length
352639-S8
Elbow (900)-with 43/64'• shank-
hose assy to valve assy
LA. LE
53-55
352640-S8
Elbow (900)-with 19/64" shank-
hose assy to cylinder assy
LA. LE
53-55
B4Q-33638-B
Washer (power steering pump
adjusting bracket)-35/64" I. D.
x 1-1/16" O. D. -(DEAD-33638-B
LA, LE
53-55
EAD-33640-A
Insulator assy (power strg. pump)
LA, LE
53_-55
352115-S32
Washer (flat)-25/64" I. D. x
1-1/8" O. D. x 7/64"
LA, LE
53-55
LA-33648-A
Locknut-7/16"-20-strg. gear
power cyl. piston rod
LA, LE
53-55
FAC-33671-A
Plate (horn blowing ring shock
pad retainer)
LA. LE
53-55
EAD-66318-A
Pulley (vibration damper)-outer
LA
53-54
EAD-66318-C
Pulley (vibration damper)-outer
LA
54
EAD-66319-B Pulley (power strg. crankshaft)
LA60-73
53
20408-S7
Bolt (hex -hd)-3/8"-16 x 1-1/8"-
pulley to crankshaft
LA60-73
53
21074-S8
Bolt (hex-hd)-5/8"-18 x 2-1/8"
-damper outer to crankshaft
assembly
LA
53-54
24428-S8
Bolt (hex-hd)-3/8"-16 x 1-1/4"
-damper outer to crank
shaft damper
LA
53-54
34807-S8
Lockwasher-3/8"-damper
outer to crankshaft damper
assy
LA
53-54
34851-S7
Lockwasher-5/8"-damper
outer pulley to crankshaft
assy
LA
53-54
Rear Axle
LA 4006-C
Axle assy (rear)-less brakes & axle shafts-3. 15 to
1 ratio-normal axle ratio for HYDRA-MATIC
transmission
LA
52
LA 4006-D
Axle assy (rear)-less brakes & axle shafts-3. 31 to
1 ratio-normal axle ratio for Dual Range HYDRA
MATIC transmission
LA
52-54
LA 4006-G
Axle assy (rear)-less brakes & axle shafts-3. 07 to
1 ratio-normal axle ratio for Dual Range HYDRA
MATIC transmission
LA
52
LE 4006-A
Axle assy (rear)-less brakes & axle shafts-3. 31 to
1 ratio-normal axle ratio for Turbo-Drive Trans
LE
55
LE 4006-B
Axle assy (rear)-less brakes & axle shafts-3. 07 to
1 ratio-normal axle ratio for Turbo-Drive Trans
LE
55
V Used with Air Conditioning - Refer to Air Conditioning Group
