LA-33569-A
Ring (strg. gear power cyL piston)
-3-19/32" I. D. x 3-3/4" O. D.
LA, LE
53-55
-also serviced in HDK-33567-A
Kit
LA-33570-A
Ring (strg. gear power cylinder
LA
53
adapter oil-"O")-3-1/2" I. D.
-also serviced in HDK-33570-A
& HDK-33580-B Kits
LA-33570-B
Ring (strg. gear power cylinder
adapter oil-"O")-3-11/32" I. D.
-also serviced in HDK-33570-B
& HDK-33580-C Kits
LA, LE
53-55
HDK-33570-A
Kit (gasket & seal)-consists of the
following
(1) LA-3581-A Gasket (1) LA-3593-A Gasket
(2) LA-33570-A Seal
(1) LA-33587-A Seal
(1) LA-33601-A Gasket (2) LA-33603-B Seal
(1) LA-33604-A Seal
(1) LA-33605-A Seal
LA
53
(8) LA-33606-A Seal
HDK-33570-B
Kit (gasket & seal)-consists o
the following
LA, LE
53-55
(1) LA-3581-A Gasket (1) LA-3593-A Gasket
(2) LA-33570-B Seal
(1) LA-33587-A Seal
(1) LA-33601-A Gasket (2) LA-33603-B Seal
(1) LA-33604-A Seal
(1) LA-33605-A Seal
(8) LA-33606-A Seal
LA-33571-B
Rack assembly (strg. gear power
LA, LE
53-55
LA-33572-A
Guide (steering gear ball return
4
LA, LE
53-55
353110-S
Ball (Steel)-9/32" diameter
60
LA, LE
53-55
LA-33573-A
Clamp (strg. gear ball return
guide)
1
LA, LE
53-55
352518-S
Screw & washer assy (fill-lid)
-1/4"-28 x 5/16"-clamp to
return guide
LA, LE
53-55
LA-33575-A
Tube assy (power strg. bleed line
LA, LE
53-55
873805
Fitting (90° elbow)-attach
power strg. bleed line
LA. LE
54-55
LA-33577-B
Valve assy (power steering gear
hydraulic control)
LA
53
LA-33577-C
Valve assy (hydraulic control)
LA, LE
54-55
LA-33578-A
Valve assy (power steering check
LA, LE
53-55
LA-33579-B
Plunger (power strg. hydraulic
control valve)
10
LA, L
53-55
LA-33580-A
Adapter assy (str. gear power
cylinder)-also serviced in
HDK-33580-B & C Kits
LA, LE
53-55
352918-S
Washer-21/32" 1. D. xl-47/64"
O. D. x 1/8" tflick-to retain
oil seal in adapter assy
LA, LE
53-55
HDK-33580-B
Kit (adapter repair)-consists o
the following
(2) LA-33570-A Seal
(1) LA-33580-A Adapter
LA
53-54
