LA 4010-A
Housing assembly (rear axle)
8M-2245 Gasket (wheel bearing retainer)-Paper
OM-1177-A
Seal assy (wheel bearing inner oil)-1/4"
thick
355765-S
Bolt (hex-hd)-1/2"-13 x 2-1/4"
-bearing
cap to differential case
34922-S Lockwasher (internal tooth)-1/2"
358048-S
Plug (pipe)-3/4"'-drain
8L 4035
Gasket (rear axle carrier cover)
8L 4067-A
Shim (differential bearing adjusting)-.
0025"/. 0035" thick
8L 4067-B
Shim (differential bearing adjusting)-.
0045••/. 0055" thick
8L 4067-C
Shim (differential bearing adjusting)-.
009"'/. 011" thick
8L 4067-D
Shim (differential bearing adjusting)-.
027"/. 033" thick
7RT 4090-MC
Hose-1/2" I. D. x 15/16" O. D.
x 36-1/4" approx. overall length
59T 4090 ME
Hose-1/2" I. D. x 15/16" O. D.
x 6-1/2" approx. overall length
LA 4090-A
N
Hose (booster to reservoir)-replaced
by LA-2905-A
8L 4109-A
Shim (driving pinion rear bearing adj.
)-. 0025"/. 0035" thick
8L 4109-B
Shim (driving pinion rear bearing adj.
)-. 0045"/. 0055" thick
8L 4109-C
Shim (driving pinion rear bearing adj.
)-. 009"'/. 011" thick
8L 4192
Cover (rear axle carrier)-without clip
20328-S7
Bolt (hex-hd)-3/811-16 x 5/81'
34807-S8
Lockwasher-3/8"
353051-S
Plug (extended head pipe)-3/4"'-filler
hole
8L 4205-A
Case (differential gear)-11/32" from
inside face of ring gear
flange to center line of differential
pinion shaft hole
8L 4205-B
Case (differential gear)-l-5/8" from
inside face of ring gear
flange to center line of differential
pinion shaft hole
357228-S
Pin (spec. lock)-15/64" x 1-7/16"
