B4A 6436-A
Seal assy (starting motor to flywheel
housing)-Steel
& Rubber-4, EBU-6436-B-also serviced
in
HFK-6008-A Kit
1
LE
EBJ 6500-A
Tappet assembly (valve)-Hydraulic
LA, LE
EAM 6500-C
Tappet asst' (valve)-Heavy Duty-also
serviced in
HDK-66005-A & B Kits
16
LA, LE
EAD-66507-A
Snap ring (valve tappet)
16
LA
EAD-66507-B
Snap ring (valve tappet)
16
LA
EAD 6505-A
Valve (exhaust)-Standard
LA
EAD 6505-B
Valve (exhaust)-. 003" O/S
as
r
LA
EAD 6505-C
Valve (exhaust)-. 015" 0 S
as
r
LA
EAD 6505-D
Valve (exhaust)-. 030" O/S
as
r
LA
EAD 6505-E
0 Valve (exhaust)-Standard
8
LA
EAD 6505-F
Valve (exhaust)-. 003" O/S
as
r
LA
EAD 6505-G
Valve (exhaust)-. 015" O/S
as
reqd
LA
EAD 6505-H
Valve (exhaust)-. 030" O/S
as
r
LA
EAD 6505-J
Valve (exhaust)-Standard-use with EAD-6049-F
head for 1953-54
8
LA, LE
EAD 6505-K
Valve (exhaust)-. 003" O/S-used
with EAD-6049-F
head for 1953-54
as
reqc
LA, LE
EAD 6505-L
Valve (exhaust)-. 015" O/S-used
with EAD-6049-F
head for 1953-54
as
reqd
LA, LE
EAD 6505-M
Valve (exhaust)-. 030" O/S-used
with EAD-6049-F
head for 1953-54
as
reqd
LA, LE
EBP 6507-E
Valve (intake)-Standard-with one slot
LA
*EBP 6507-F
Valve (intake)-. 003" O/S-with
one slot
as
reqd
LA
*EBP 6507-G
Valve (intake)-. 015".O/S-with
one slot
as
r
LA
*EBP 6507-H
Valve intake)-. 030" O/S-with one
slot
as
r
LA
EAM 6507-E
Valve (intake)-Std. -with two slots
at end of stem
LA
EAM 6507-F
Valve (intake)-. 003" O/S-with
two slots at end o
stem
as
r
LA
EAM 6507-G
Valve (intake)-. 015" O/S-"C"
cast on head-with
two slots at end of stem
as
regd
LA
EAM 6507-H
Valve (intake)-. 030" O/S-"D"
cast on head-with
two slots at end of stem
as
reqd
LA
* Use B4Q-6571-A when used in place
of EAM-6507-E, F, G or H valves
Flywheel and valves Continued
EAD 6507-B
Valve (intake)-Standard
8-
LA
EAD 6507-K
Valve (intake)-. 003" O/S
as
r
LA
EAD 6507-L
Valve (intake)-. 015" O S
as
reqd
LA
EAD 6507-M
Valve (intake)-. 030" O/S
as
reqd
LA
