EAD 6674-B
Plunger (oil pump relief valve)-1/2"
maximum 0. D.
x 1-15/16" long
1
LA, LE
52-55
Oil Pan
EAD 6675-B
`
Pan assembly (oil)
1
LA
52-54
EAD 6675-C
Pan assembly (oil)
1
LA, LE
54-55
42719-S Screw (hex-hd)-5/16"-18
x
5/8"-oil pan to cyl. block
and front cover
21
LA, LE
52-55
HACK 6675-A
Kit (engine gasket-lower)-consists of
the following
(1) LA-6411-B Seal
(1) EAD-6625-B Gasket
(1) EAD-6648-B Gasket (2) EAD-6701-A
Seal
(2) EAD-6702-A Seal
(1) EAD-6710-A Gasket
(1) 86H-6734
Gasket (1) EAD-9417-A Gasket
(1) B2Q-6643-B Seal
1
LA
52-54
HACK 6675-B
Kit (engine gasket-lower)-consists
of the following
(1) LA-6411-B Seal
(1) EAD-6625-B Gasket
(1) EAD-6648-B Gasket (2) EAD-6701-A
Seal
(2) EAD-6702-B Seal
(1) EAD-6710-A Gasket
(1) 86H-6734
Gasket (1) EAD-9417-A Gasket
(1) B2Q-6643-B Seal
1
LA
54
HACK 6675-C
T Kit (engine gasket-lower)-consists
of the following
(1) LA-6411-B Seal
(1) LE-6411-A Seal
(1) B4A-6625-A Gasket (1) B4A-6648-A
Gasket
(2) B4Q-6701-A Seal
(2) EAD-6702-B Seal
(1) B4Q-6710-A Gasket (1) 86H-6734
Gasket
(1) EAD-9417-A Gasket (1) B4A-6643-A
Seal
LE
55
B4A 6698-A
Seal (oil pan to oil pump tube)-Rubber-5/8"
I. D. x
29/32" 0. D. x 15/32" long-EBY-66642-A-
also serviced in HFK-6008-A Kit
1
LA, LE
54-55
EAA 6700-B
Seal assy (crankshaft front oil)-2-9/16"
0. D. x
1-53/64" I. D. x 5/16" thick-also
serviced in
HEK-6008-D, HCK-6781-A, B, HFK-6008-A,
HCK-6059-A & B Kits
1
LA, LE
52-55
EAD 6701-A
Seal (crankshaft rear oil)-5-1/21'
long-also
serviced in HCK-6675-A, B, HCK-6781-A
& B
2
LA
52-54
B4Q 6701-A
Seal (crankshaft rear oil)-5-1/2"
long-®EAD-6701-B
-also serviced in HEK-6008-D, HCK-6675-C,
HCK-6781-B and HFK-6008-A Kits
2
LA, LE
52-55
EAD 6702-B
Seal (crankshaft rear main bearing
cap)-also
serviced in HEK-6008-D, HCK-6675-B,
C,
HCK-6781-B and HFK-6008-A
2
LA, LE
52-55
EAD 6710-A
Gasket (oil pan)-Cork-also serviced
in
HCK-6675-A, B HCK-6781-A & B Kits
1
LA
52-54
B4Q 6710-A
Gasket (oil pan)-®EAD-6710-B-also
serviced in
HEK-6008-D, HCK-6675-C, HFK-6008-A
1
LA, LE
54-55
8HA 6730
Plug (oil pan drain)-7/8"-16
1
LA, LE
52-55
