B5S 7015-A
Shaft assembly (transmission input)
-PMB-7015-A
B5S 7019-A
Washer (transmission input shaft thrust)
-PMB-7019-A
357916-S
Plug (dry seal pipe)-1/8"-27-to
plug mfg.
holes in transmission case
1L 7030-A
Snap ring (trans. output shaft bearing
retaining)-2-37/64" O. D.
x 2-17/64" 1. D.
1P 7034-A
Vent assembly (transmission case)
O1Y 7039
Kit (universal joint)-consists of the
following
(4) 01Y-7074
Bearing
(1) OIY-7084
Spider
(4) O1Y-7096
Snap ring
81A 7059
Snap ring (trans. main shaft)-. 086"/.
088" thick-retains
speedometer drive gear on shaft
1L 7070-A
Spacer (trans. output shaft rear bearing)-1-9/16"
O. D. x 1-25/64"
I. D. x 1-5/16" thick
01Y 7074
NS
Bearing assy (universal joint)-serviced
in OIY-7039 Kit
