8L-77127
Screw & washer assy (fillister hd)-No.
10-24
x 7/16"-front valve body cover plate
8L-77127
Screw & washer assy (fillister hd)-No.
10-24
x 7/16"-outer valve body front cover
LA-77130-A
Governor assembly (transmission)
24404-S7
Bolt (hex-hd)-1/4"-20 x 1-1/8"
34940-S2
Lockwasher (external tooth)-1/4"
358498-S
Screw & washer assy (fill-hd)-No.
10-24 x 7/16"
-governor bushing retainer to governor
body
1P-77130-A
Governor assembly (transmission)
1P-77131-A
Body assy (trans. governor)-less counterweight
353078-S
Ball (steel)-1/4" dia.
31128-S Bolt (fillister head)-1/4"-20
x 1"-governor
body to governor counterweight
34805-S8
Lockwasher-1/4"
8L-77135
Lock (transmission reverse anchor support
bolt)
1P-77135-A
Cover (trans. governor valve body)
357846-S
Screw (flat head)-No. 10-24 x 3/8"
1P-77136-A
Snap ring (trans. governor retaining)
1L-77138-A
Cover (transmission extension housing
access
357144-S
Bolt (hex-hd)-1/4"-20 x 9/16"-cover
to
extension
34805-S8
Lockwasher-1/4"-cover to extension
1P-77138-B
Cover (trans. governor inspection)-oblong
31064-S7
Bolt (fillister head)-1/4"-20 x
1/2"
inspection cover to extension
357914-S
Washer (flat)-1/4" I. D. x 7/16"
O. D. x
1/16" thick-Fibre
1L-77139-A
Gear assy (trans. reverse internal)
LA-77139-A
Gear assy (trans. reverse internal)
NS
HEK-77139-A
Kit (trans. reverse internal gear,
washer
& spring)-consists of the following
(1) LA-77139-A Gear (1) LA-77592-A
Spring
(1) LA-77590-A Washer-Service Details
1P-77139-B
Gasket (trans. governor inspection
cover)
Cork-oblong
1L-77140-A
Carrier assembly transmission reverse
planet)
8L-77141
Bearing assy (transmission output shaft)
8L-77142
Snap ring (trans. rear oil pump gear
retaining)
8L-77144
Bearing (needle)-. 0070"/. 0772"
dia. x 3/4"
overall length
1L-77146-A
Washer (transmission reverse internal
gear
thrust)-3-1/4" O. D. x 2-9/16-1.
D. x 3/32" thick
8L-77148
Snap ring (transmission reverse planet
carrier
retaining)-1. 322"/1. 342"
I. D. x 1. 572"/1. 592"
O. D. x .092"/. 094" thick
8L-77152
Gear (transmission rear oil pump drive)
353080-S
Ball-3/16" dia. -pump driver gear
8L-77153
Washer (trans. reverse sun gear thrust)-Bronze-
1-11/16" I. D. -2-19/32" O.
D. x . 087"/. 091"
thick
8L-77154
Washer (transmission reverse sun gear
backing
thrust)-Steel-1-1/2" I. D. -2-7/16"
O. D. x
. 049"/. 052" thick
1L-77155-A
Spring (transmission reverse blocker
piston)-
5/16" O. D. x approx. 15/17"
free length
1L-77161-A
Gasket (trans. extension housing access
cover)-
also serviced in HAK-7086-B Kit
