1P-77283-A
Lever (trans. throttle control)-inner
355949-S
Locknut (hex)-5/16"-24-attach lever
to
throttle control shaft
357234-S
Pin (straight)- 1/4" x 5/16"-use
with detent
lever
8L-77284
Lever assy (trans. inside throttle valve
control)
72187-S7
Pin (grooved)-1/16" x 1/2" throttle
valve
control lever
351543-S
Washer (flat)-5/16"-to remove throttle
shaft
end play
1L-77285-A
Retainer assembly (transmission detent
plunger)
34803-S7
Lockwasher-No. 10-use with 356746-S
356746-S
Screw (fillister head)-No. 10-24 x
3/4"-
retainer detent plunger to outer valve
body
B5A-77288-A
Seal assy (trans. manual control)-lined
with
Rubber-1-1/16" O. D. x 3/16"
wide-DlP-77288-B
1L-77294-A
Piston (transmission reverse shifter
blocker)-
11/16" O. D. x 7/8" long-slotted
1L-77295-A
Bracket & crank assy (trans. reverse
shifter)
LA-77295-A
Bracket & crank assy (trans. reverse
shifter)
352794-S8
Bolt (hex head)-5/16"-18 x 2-1/16"
34806-S7
Lockwasher-5/16"
8L-77299
Roller (transmission reverse shifter
crank)-5/16"
I. D. x 3/4" O. D. x 1/4" thick
1P-77303-A
Lever assy (trans. parking pawl toggle
operating)
74275-S Retainer (spring)-for 5/16"
grooved dia. -
to retain parking pawl toggle lift
lever
1P-77304-A
Lever (trans. parking pawl torsion
spring)
1P-77307-B
Spring (trans. parking pawl torsion)-1/8"
dia.
1P-77308-A
Pin (trans. parking pawl torsion lever
support)-
9/16" max. dia. x 2-1/2" o/all
length
grooved at end
356415-S
Washer (flat)-25/64" I. D. -use
with parking
pawl toggle lever pin
1L-77311-A
Pawl (transmission parking)
B4A-77311-A
Pawl (trans. parking)-(i,1P-77311-B
1L-77312-A
Screw (hex-hd dog point)-7/16"-20
x 3"-trans.
parking pawl support
1 P-77312-A
Pin (trans. parking pawl support)-15/32"
0. D.
x 2-1/32" long
1L-77313-A
Spring (transmission parking brake
pawl return)-
18 coils-1-3/4" long
1P-77314-A
Spring (trans. parking pawl toggle
return)-
approx. 3 coils-hooked type ends
1P-77315-A
Lever (trans. parking pawl toggle)
1P-77316-A
Link (trans. parking pawl toggle)
74274-S Retainer (spring)-for 1/4"
grooved dia. -
to retain parking pawl toggle pin
1P-77317-A
Pin (trans. parking pawl toggle lever)-5/16"
0. D.
x 39/64" o/all length
1P-77318-A
Pin (trans. parking pawl toggle link)-5/16"
O. D.
x 1" long
