HCK 6149-A
Kit (piston ring set)-Standard
LA
52-54
HCK 6149-B
Kit (piston ring set)-. 020" O/S
LA
52-54
HCK 6149-C
Kit (piston ring set)-. 030" O/S
1
LA
52-54
HCK 6149-D
Kit (piston ring set) .040" O/S
LA
52-54
HFK 6149-A
, Kit (piston ring set)-Standard
1
LE
55
HFK 6149-B
, Kit (piston ring set)-. 020" O/S
1
LE
55
HFK 6149-C
Kit (piston ring set)-. 030" O/S
LE
55
HFK 6149-D
Kit (piston ring set)-. 040" O/S
LE
55
EAD 6200-A
Rod assembly (connecting)
8
LA
52-54
B5Q 6200-A
, Rod assembly (connecting)- EBB-6200-A
LE
55
EAA 6207-A
Bushing connecting rod)
LA, LE
52-55
EAD 6211-L
Bearing (cone. rod)-Std. -Red size-Lead
Babbitt
16
LA
52-54
EAD 6211-M
Bearing (cone. rod)-Std. -Blue size-Lead
Babbitt
16
LA
52-54
EAM 6211-C
Bearing (cone. rod)-. 010" U/S
16
LA
52-54
EAM 6211-D
Bearing (cone. rod)-. 020" U/S
16
LA
52-54
EAM 6211-E
Bearing (cone. rod)-. 030" U/S
16
LA
52-54
EAM 6211-F
Bearing (conn. rod)-. 040" U/S
16
LA
52-54
EAM 6211-G
Bearing (corn. rod)-Std. -Red size-Copper
Lead
16
LA
54
EAM 6211-H
Bearing (corn. rod)-Std. -Blue size-Copper
Lead
16
LA
54
B5Q 6211-A
Bearing (conn. rod)-Std. -Red size-Copper
Lead
alloy-EAM-6211-K
16
LE
55
B5Q 6211-B
Bearing (conn. rod)-Std. -Blue size-Copper
Lead
alloy-EAM-6211-L
16
LE
55
B5Q 6211-C
Bearing (conn. rod)-. 010" U/S-EAM-6211-M
16
LE
55
B5Q 6211-D
Bearing (conn. rod)-. 020" U/S-EAM-6211-N
16
LE
55
B5Q 6211-E
Bearing (conn. rod)-. 030" U/S-EAM-6211-R
16
LE
55
B5Q 6211-F
Bearing (conn. rod)-. 040" U/S-EAM-6211-S
16
LE
55
354128-S
Nut (hex hd slotted)-3/8"-24
-connecting rod
16
LA, LE
54-55
7HA 6212
Nut (hex head slotted)-3/8"-24-connecting
rod
16
LA
52-54
45218-S8
Nut (stamped)-3/8"-24
16
LA, LE
52-55
EAA 6214-B
Bolt (connecting rod)-3/8"-24 x
2-1/16"
16
LA, LE
52-55
Camshaft and Crankshaft
EAD 6250-D
r Camshaft
LA
~ 52-53
EAD 6250-E
_
Camshaft-Heavy Duty-also serviced in
HDK-66005-A & B Kits
LA
53-54
EAD 6250-F
Camshaft
1
LA
54
EBB 6250-A
Camshaft
1
LE
55
EAD 6256-A
Sprocket (camshaft timing chain)
1
LA
52
EAD 6256-B
Sprocket (camshaft timing chain)
1
LA, LE
_
EAD 6258-A
Ring (camshaft sprocket lock)
1
LA, LE
52-55
EAD 6261-C
Bearing (camshaft front and rear)-Std.
-reamed
2
LA, LE
52-55
EAD 6262-C
Bearing (camshaft center)-Std. -reamed
3
LA, LE
52-55
EAD 6266-A
Plug (camshaft rear bearing)-2-17/64"
max. O. D.
1
LA, LE
52-55
EAD 6268-A
Chain (timing)
1
LA
52-54
B4Q 6268-A
Chain (timing)- ®EAD-6268-B
1
LA, LE
54-55
6 Basic No. 6149 contains the necessary
compression rings nil control
rims expanders & segments
