Muffler
BT 5202-A
Extension assy (muffler outlet pipe)
LE
55
BT 5203-A
Extension assy (muffler outlet pipe)
1
LE
55
LA 5212-F
Resonator assy-front
1
LA
52
LA 5212-K
Resonator assy-front
1
LA
52-54
LE 5212-A
Resonator assy
2
, LE
55
33798-S8
Nut (hex)-5/16"-18-front
resonator to muffler assy
2
LE
52-55
357624-S7
Lockwasher-5/16"-resonator
assy to muffler assy
2
LA
52-55
LA 5230-E
Muffler assy
1
LA
52
LA 5230-K
Muffler assy
1
LA
52-54 ,_
LE 5230-A
Muffler assy
2
LE
55
357624-S7
Lockwasher-5/16"-muffler
assy to pipe muffler to
rear resonator
2
LA
54
33798-S8
Nut (hex)-5/16"-18-muffler
assy to pipe muffler to rear
resonator
2
LE
52-55
LE 5231-A
Bracket & insulator assy (muffler outlet pipe)-
upper-front R. H.
1
LE
55
LE-55233-A
Pipe assy (muffler inlet rear)-
L. H.
1
LE
55
357624-S7
Lockwasher-5/16"-pipe assy
-muffler inlet-rear L. H. to
muffler assy
2
LE
55
33798-S8
Nut (hex)-5/16"-24-pipe assy
-muffler inlet rear L. H. to
muffler assy
2
LE
55
DEAD-55236-A Elbow (exhaust manifold cross-
over pipe)
1
LA
54
20347-S8
Bolt (hex-hd)-5/16"-24 x 3/4"-
brkt. & insulator assy outlet
pipe upper front to frame
R. H.
2
LE
55
357624-S7
Lockwasher-5/16"-brkt. &
insulator assy-muffler
outlet pipe upper front
to frame-R.H.
2
LE
55
33798-S8
Nut (hex)-5/16"-24-brkt. &
insulator assy outlet pipe
upper front to frame-R. H.
2
LE
55
LA 5246-A
Pipe assembly (muffler inlet)-curved-2-1/2" O. D.
1
LA
52
LA 5246-B
Pipe assembly (muffler inlet)-curved-2-1/4" O. D.
1
LA
53-54
LE 5246-A
Pipe assembly (muffler inlet)-R. H.
1
LE
55
357624-S7
Lockwasher-5/16"-pipe assy
muffler inlet R. H. to
muffler assy
2
LE
55
357625-S7
Lockwasher-7/16"-muffler
inlet pipe assy to exhaust
manifold
2
LE
55
357629-S7
Lockwasher-3/8" -inlet pipe to
exhaust manifold
4
LA
52-54
1
