1. Remove the vacuum connection
2. Remove the governor cover safety
wire and seal. Remove the four governor
cover
screws and lockwashers. Remove the
governor
cover and discard the gasket.
Figure 30.
Governor Cover Removed
3. Ease the governor spring off
the
posts. Do not distort the spring
in any way during
removal, as the governor operation
may be im
paired.
The governor spring post in the
governor
housing should not be removed (Figure
No.
36).
If it is necessary to replace this
post, make
sure the new post is installed in
the proper
4. Remove the governor lever nut
and
lockwasher. Remove the diaphragm
rod cotter
pin.
Slide the governor lever off the
throttle
5. Remove the three governor to
throttle
body screws and lockwashers.
6. Remove the governor housing,
gasket, throttle shaft seal, seal
retainer, and
bearing retainer spring. Discard
the gasket and
leather seal.
7. Remove the diaphragm cover safety
wire and seal. Remove the eight
diaphragm cover
screws and lockwashers. Remove the
diaphragm
cover and the diaphragm. and rod
assembly.
jets.
springs.
10.
Remove dashpot adjusting screw and
nut from throttle lever clamp --
automatic trans
mission.
11. Remove throttle lever clamp
screw
and nut, and the throttle lever.
Remove the two
throttle operating shaft housing
screws and lock
washers, the throttle operating
shaft and housing
assembly and discard the gasket.
NOT
8. Remove the two governor by-pass
Figure 31. Governor Housing Removed
9. Remove idle adjusting needles
and
