Part Name
Basic
Part No.
Part Name
Basic
Part No.
Shim (front spring)
5355
Spacer (horn bracket)
13827
Shim (front suspension lower arm front
3054
Spacer (muffler heat deflector to floor)
55296
bolt)
Spacer (ornament)
8219
Shim (front suspension upper arm mounting)
3043
Spacer (radiator grille to bumper bar)
88213
Shock absorber assy
18045
Spacer (spring clamp)
5703
Shock absorber assy
18080
Spacer (steering column hsg. to
fender
3667
Shim (strg. gear power rack cover)
33594
Spacer (steering gear housing to frame)
3566
SHOCK ABSORBER GROUP (Page 325)
Spacer (steering gear shaft bearing)
33518
Shoe and lining (front)-Primary
2018
Spacer (trans. control valve detent plunger
ret.)
77208
Shoe and lining (front) -Secondary
2019
Spacer (trans. coutershaft gear bearing)
7125
Shoe and lining (rear)-Primary
2218
Spacer (trans. gear shift arm hub)
7336
Shoe and lining (rear) -Secondary
2019
Spacer (trans. low oil pressure regulator
valve)
7470
Shoe and lining (rear) -Secondary
2215
Spacer (trans. oil distributor tube)
77785
Sleeve (power strg. pressure hose insulator)
33595
Spacer (trans. output shaft rear bearing)
7070
Sleeve (steering column bearing)
3518
Spacer (trans. reverse planet carrier)
77179
Sleeve (trans. clutch & governor
oil
77882
Spacer (valve spring)
6515
Sleeve (trans. gear shift rod adjustment)
7353
Spacer (water pump pulley to fan)
8546
Sleeve (trans. line exhaust valve)
77447
Spacer assy (W/S wiper mounting)
17519
Sleeve (valve spring retainer)
6517
Spacer assy (W/S wiper mounting)
17520
Sleeve (wire terminal insulating)
14455
SPARE WHEEL CLAMPS GROUP (Page 2)
Sleeve assy (drag link adjusting)
3310
Speedometer assy (miles)
17255
Sleeve assy (trans. oil supply to clutches)
77027
SPEEDOMETER GROUP (Page 301)
Slinger (driving pinion shaft oil)
4670
Spindle assy (front wheel)
3105
Slinger (water pump shaft)
8550
Spotlight assy (utility hand)
18148
Snap ring (brake master cylinder piston)
2174
SPOTLIGHT GROUP (Page 417)
Snap ring (converter stator clutch)
7945
SPOTLIGHT MIRROR GROUP (Page 418)
Snap ring (torus retaining)
7917
Spring (accel. shaft retracting)
9737
Snap ring (trans. driven torus)
7927
Spring (brake adjusting screw)
2049
Snap ring (trans. front band servo piston
ret.)
77366
Spring (brake booster body piston reaction)
22358
Snap ring (trans. front clutch cylinder)
77567
Spring (brake booster body piston return)
2361
Snap ring (trans. governor retaining)
77136
Spring (brake booster check valve)
22371
Snap ring (trans. main shaft)
7059
Spring (brake drum silencer)
1140
Snap ring (trans. output shaft bearing
7030
Spring (brake master cylinder outlet
valve)
2183
Snap ring (trans. output shaft center
bearing
77069
Spring (brake pedal retracting)
2472
Snap ring (trans. rear band servo piston
ret. )
77417
Spring (brake shoe hold down)
2068
Snap ring (trans. rear clutch piston
spring
77517
Spring (brake shoe retracting)
2035
Snap ring (trans. rear clutch plate retainer)
77523
Spring (brush holder)
14576
Snap ring (trans. rear oil pump gear
77142
Spring (brush holder)
14595
Snap ring (trans. reverse clutch piston
spring 77596
Spring (camshaft piston thrust)
6276
Snap ring (trans. reverse planet carrier
77148
Spring (carb. accel. pump)
9986
Snap ring (universal joint spider brg.
7096
Spring (carb. accel. pump check ball
retainer)
9575
Snap ring (water pump housing)
8576
Spring (carb. accel. pump piston operating
rod)
9636
Snap ring (water pump shaft bearing retainer)
8630
Spring (carb. accel. pump piston return)
9636
Socket (brake adjusting screw)
2048
Spring (carb. filter screen retainer)
9937
Socket (roof rail lamp)
13721
Spring (carb. float)
9958
Socket (trans. control selector lever)
7228
Spring (carb. idle adjusting needle)
9578
Socket and retainer assy (cigar lighter)
15055
Spring (carb. secondary throttle diaphragm
99511
Socket and wiring assy (parking lamp)
13234
Spring (distributor diaphragm)
12225
Socket and wiring assy (rear lamp)
13410
Spring (distributor primary)
12192
Solution (W/S washer)
19550
Spring (distributor shaft)
12213
Spacer (back up lamp)
15532
Spring (front)
5310
Spacer (carburetor)
9603
Spring (front wheel brake cylinder piston
return)
2205
Spacer (exhaust manifold to cylinder
head)
9438
Spring (front wheel brake shoe adjusting
22050
Spacer (fender bracket
16195
Spring (fuel & vacuum pump rocker
arm)
9380
Spacer (front bumper lower arm to frame)
17765
Spring (fuel pump
9396
Spacer (front fender to rocker panel)
16248
Spring (gear shift anti vibrator)
7242
Spacer (front stabilator
5490
Spring (generator bearing)
10087
Spacer (fuel & vacuum link &
spring retainer)
9382
Spring (generator brush)
10057
