Part Name
Basic
Part No.
Part Name
Basic
Part No.
Screw (generator rear end plate terminal)
10211
Seat (front stabilizer insulator)
18031
Screw (generator terminal)
10211
Seat (front suspension arm rear mounting
bolt)
3085
Screw (headlamp adjusting)
13032
Seat (power strg, reservoir element spring)
33540
Screw (internal gear)
77077
Seat (rear shock absorber insulator)
18172
Screw (rd-hd slotted shoulder)
10211
Seat (steering corn. link ext. ball stud
spring)
3326
Screw (starter pole piece)
10044
Seat (trans. oil pressure regulator valve
77466
Screw (steering sector shaft thrust)
3577
Seat (trans, rear clutch piston spring)
77516
Screw (trans. parking pawl support)
77312
Seat (trans. rear pump check valve)
77712
Screw (valve adjusting)
6549
Seat (vacuum pump diaphragm spring)
9302
Screw and washer assy (trans. frt. valve)
77126-7
Selector (carburetor floor bawl vent)
99608
Screw and washer assy (trans. outer valve)
77361
Selector assy (trans. control)
7200
Screw and washer assy (trans. outer valve)
77633
SERVICE BRAKES GROUP (Page 2)
Scoop assy (outside air intake)
19884-5
Shaft {brake master cyl, operating lever)
2482
Seal (blower to package
19938-9
Shaft (brake pedal)
2478
Seal (converter housing front cover)
6411
Shaft {differential pinion)
4211
Seal (crankshaft rear main bearing cap)
6702
Shaft (front suspension upper arm)
3056
Seal (crankshaft rear oil)
6701
Shaft (madulator valve manual control)
19970
Seal (flywheel hsg. front cover)
6411
Shaft (speedometer cable)
17262
Seal (front fender to body pillar)
1624
Shaft (trans. front band actuating lever)
77355
Seal (front fender to cowl)
1612
Shaft (trans. rear band actuating lever)
77411
Seal (front suspension upper arm ball
joint
3305
Shaft (valve rocker arm)
6563
Seal (hood hinge bracket to body)
1687
Shaft and bearing assy (rear axle)
4234
Seal (intake valve stem)
6571
Shaft and bracket assy (accelerator)
9725
Seal (oil anti drain back)
6804
Shaft and lever assy (carb, choke)
9546
Seal (oil pan to oil pump tube)
6698
Shaft and lever assy (carb, choke housing)
9955
Seal (oil pump inlet tube)
6643
Shaft and ring gear assy (output)
7705
Seal (oil reservoir cover)
6570
Shaft and universal joint assy {drive)
4602
Seal (outside air intake scoop)
1989
Shaft and worm assy (steering column)
3524
Seal (parking lamp splash shield)
1614
Shaft assy (distributor)
1217
Seal {power steering oil reservoir)
6570
Shaft assy (oil pump intermediate)
6627
Seal (radiator splash
8825
Shaft assy (outside air intake flue damper
1988
Seal {radiator splash shield front center)
8829
Shaft assy (outside air intake flue damper
1991
Seal (rear stone deflector)
1783
Shaft assy (steering gear sector)
3575
Seal (rear stone deflector to bumper)
17844-
Shaft assy (trans. control to accel.
)
7723
Seal (speedometer drive gear oil)
1729
Shaft assy (trans. input)
7015
Seal (strg. gear power cyl. piston rod
oil)
3356
Shaft assy (trans. output)
7706
Seal (strg. gear sector shaft grease)
3358
Shield (accel. pedal dust)
9776
Seal (steering idler arm)
3359
Shield (brake master cyl, heat)
2213
Seal (steering linkage ball stud)
3332
Shield (fan and water pump belt)
8579
Seal (trans. front cover oil)
7733
Shield (fan belt idler pulley bearing
dust)
8687
Seal (trans. front pump intake pipe)
7735
Shield (front fender splash rear)
16102-3
Seal (trans. pressure regulator to case)
7735
Shield (front suspension upper arm ball
joint
3305
Seal (universal joint
7078
Shield (parking lamp
16176-7
Seal (valve rocker arm cover stud)
6570
Shield (radiator splash)
1655
Seal (valve stem)
6571
Shield (roadlamp anti-reflection)
15252-
Seal assy (crankshaft
6700
Shield (spark plug ignition wire)
1229
Seal assy (power strg. gear hydraulic-valve}
3356
Shield (steering corm. link ext. ball
stud-dust)
3343
Seal assy (rear axle driving pinion oil)
4676
Shield (trans, extension rear oil seal)
7692
Seal assy (starting motor to flywheel
hsg. )
6436
Shield assy (brake master cyl. )
2213
Seal assy (steering gear hsg. oil)
3591
Shield assy (exhaust crossover pipe heat)
5527
Seal assy (steering gear worm oil)
3356
Shield assy (generator splash)
1016
Seal assy (trans. manual control)
7728
Shield assy (radiator
8209
Seal assy {water pump)
8564
Shield assy (roadlamp anti-reflecting)
15276-'1
Seal assy (wheel bearing inner oil)
1177
Shield assy (trans. extension oil seal
dirt)
7765
Sealer (compound)
1955
Shim {differential bearing adjusting)
4067
Sealer (steering column opening)
3513
Shim {driving pinion front bearing adj.
)
4672
Seat (front shock absorber insulator)
1803
Shim (driving pinion rear bearing adj.
)
4109
