Part Name Part No. Part Name Part No. Guard assy (front bumper grille) 17939 Hose (radiator)-upper 8260 Guard assy (front bumper) 17916-7 Hose (radio antenna) 18931 Guard assy (front bumper) 17924-5 Hose (water by pass tube) 8548 Guard assy (front bumper) 17996-7 Hose (W/S washer} 17580 Guard assy (rear bumper) 17984-5 Hose (W/S wiper and booster to manifold) 17543 Guide (hood lock lever) 16961 Hose and sleeve assy (power strg. return line) 3659
Gauge (oil pressure)
9278
Guide (hood lock spring)
16927
Gear (differential side)
4236
Guide (strg, gear ball return)
33572
Gear (distributor driven)
12390
Guide (strg, gear power rack)
33585
Gear (oil pump driven)
6610
Guide (trans. front oil pump relief valve)
7735?
Gear (rear internal)
77072
Guide (trans, 0/Drive shift rail)
7696
Gear (speedometer drive)
17285
Gusset (radiator air deflector to fender)
8184-5
Gear (trans. rear oil pump drive)
77152
Gear (trans. reverse internal)
77139
H
Gear and flange assy (trans. reverse sun)
77170
Gear and shaft assy (trans. main drive)
77017
Hair (fuel pump body curled)
9486
Geax assy (oil pump drive}
6608
Handle (heater def, outlet door)
19203
Gear assy (speedometer driven)
17271
Handle and shank assy (turn signal switch}
133 05
Gear assy (speedometer driven)
17322
Hanger (front bumper)
17754
Geax assy (steering)-less tube and flange
3504
Hanger (front bumper)
17770
Gear assy (trans. front clutch)
77530
Hanger (front bumper)
17766
Gear assy (trans. front drive)
77337
Hanger (front bumper)
17782
Gear shift assy (transmission)
72oa
Hanger (front bumper}
17783
Generator assy (less pulley, bracket and bolt)
10002
Hanger (rear bumper)
17787-8
GENERATOR CHART (Page 221)
Hanger (rear bumper)
17795
GENERATOR GROUP (Page 219)
Hanger (rear bumper)
17796
Governor assy (transmission)
77130
Hanger (rear spring shackle)
5610-11
Governor assy (transmission)
77390
Hanger assy (rear spring)
5770-75
Grease (distributor)
19575
Head (cylinder)
6049
Grease (wheel bearing)
19585
Head (cylinder)
6085
Grease retainer assy (front wheel)
1190
HEADLAMP GROUP (Page 238)
Grille (air intake)
19744
Headlamp assy-less bulb and wiring
13008
Grille (rear window defroster)
18640
Heater and defroster (fresh air hot water)
18455
Grille assy (air intake)
19742-3
Heater assy (underseat)
18467
Grille assy (radiator lower center)
8202
Hinge assy (hood)
16796-7
Grille assy (radiator lower outer)
88211
Hinge assy (rear license plate support)
13431
Grille assy (radiator)-upper
882 84
Holder (brush}
14575
Grommet (air control)
18912
Holder assy (fuse to air conditioner blower switch)
14411
Grommet (antenna lead-in seal)
18912
HOOD GROUP (Page 290)
Grommet (electric wiring)
14567
Hood assy-less ornaments
16611
Grommet (evaporator tube to floor)
19957
Hook assy (hood auxiliary catch)
16892
Grommet (fuel tank filler)
9080
HORN GROUP (Page 255)
Grommet (fuel tank gage wire thru rear floor pan)
14567
Horn assy (low pitch)
13832
Grommet (fuel tank vent pipe)
99068
Horn assy (high pitch)
13833
Grommet (fuel tank vent tube)
9024
Hose (blower to evaporator)
19956
Grommet (heater blower motor mounting)
18605
Hose (blower to package tray)
19956
Grommet (ignition cable)
12297
Hose (booster to reservoir)
4090
Grommet (instrument panel wiring thru dash)
14567
Hose (brake reservoir outlet)
22350
Grommet (interior lamp feed wire thru L. H.
14567
Hose (brake reservoir to booster)
22907
window regulator panel)
Hose (brake reservoir to booster tube)
2905
Grommet (parking lamp wire thru air deflector)
14fi15
Hose (engine to heater water control valve}
18648
Grommet (rear lamp wiring thru pillar)
14603
Hose (evaporator drain)
19858
Grommet (steering column to dash)
3512
Hose (fresh air intake to evaporator)
19977
Grommet (top control relay to circuit breaker)
18912
Hose (fuel tank vent pipe)
9170
Grommet (valve push rod cover stud)
6589
Hose (heater)
18472
Grommet (W/S washer-hose)
17673
Hose (heater defroster)
18556
Grommet assy (package tray to roof duct}
19942
Hose (radiator drain)
8081
Guard assy (front bumper grille)
17938
Hose (radiator)-lower
8286
