t LA 3524-B
Shaft and worm assy (steering gear)-19.
8 to 1 ratio
LA, LE
53-55
B 3538
Plug (steering gear oil filler)-3/4"-20
tapped hole
LA, LE
52-55
78 3539-A
Locknut assy (steering thrust screw)-1/2"-20
tapped hole
LA, LE
52-55
LA 3548-B
Housing and bushing assy (steering gear)
LA, LE
52-55
t LA 3548-D
Housing assembly (steering gear)
LA
53-54
t LA 3548-E
Housing assembly (steering gear)
LA, LE
54-55
8L-33576
Bearing (steering gear shaft)-
needle point roller type
LA, LE
52-55
LA-33518-A
Spacer (steering gear shaft
bearing)-1-1/2" O. D. x
3-7/16" long
LA. LE
52-55
LA 3552-A
C p (steering gear worm bearing)-lower
LA, LE
52-55
81T 3553
Cup (steering gear worm)-11/16" wide
x 2-1/4"
O. D.
LA. LE
52-55
t LA 3553-A
Bushing (strg. gear pitman shaft)-1-15/64"
I. D. x
1-1/4" O. D. x 1-3/8" long
LA
53-54
t LA 3553-B
Bushing (steering gear pitman shaft)-1-1/8"
I. D.
x 1-1/4" O. D. x 1-3/8" long
LA, LE
54-55
78 3564
Washer (steering thrust screw lock)-6
pointed with
lettering "This Side Up".
LA. LE
53-55
LA 3565-A
Cylinder & rack assembly (power steering)
LA
53
t LA 3565-B
Cylinder & rack assembly (power steering)
LA, LE
54-55
MA 3566-A
Spacer (steering gear housing to frame)-.
030"
thick
as
reqd
LA, LE
52-55
MA 3566-B
Spacer (steering gear housing to frame
-. 010"
thick
as
reqd
LA. LE
52-55
81T 3571-A
Roller assy (steering gear worm bearing)
2
LA, LE
52-55
LA 3575-A
Shaft assy (steering gear sector)-20.
4 to 1 ratio
LA, LE
52-55
t LA 3575-C
Shaft assy (steering gear sector)-19.
8 to 1 radio
LA, LE
53-55
78 3577
Screw (steering sector shaft thrust)-1/2"-20
x
1-1/4" overall length
LA. LE
52-55
7RT 3579
Washer (steering sector shaft thrust)-7/8"
square
x 33/64" hole x 53/64" thick
LA, LE
52-55
7RT 3580
Cover (steering gear housing)
LA, LE
52-55
350997-S
Screw (hex-hd)-5/16"-18 x
9/16"-cover to steering
housing assembly
LA. LE
52-55
7RT 3581
Gasket (steering gear housing cover)
LA, LE
52-55
t LA 3581-A
Gasket (strg. gear hsg. sector shaft
cover)-3-
17/64" 1. D. hole
LA, LE
53-55
8M 3582
Plug (steering gear worm cover)-17/32"
O.D. x
17/64" overall thickness-concave
type
LA
52-54
