8L-7285-C
Lever (transmission outer shift)
LA-7285-B
Lever (transmission outer shift)
50191-S Bolt (cross recessed fillister head)-5/16"-
24 x I-outer shift lever
*LA-7325-B
Rod assy (trans. manual shift)-Single Range
*LA-7325-D
Rod assy (trans. manual shift)-Dual Range
*LA-7325-E
Rod assy (trans. manual shift)-Dual Range
B5A-7330-B
Lever assy (transmission front band actuating)-
PMB-77354-C
PMC-7366-A
Piston (transmission front band servo release)
42802-S8
Screw & lockwasher assy (pan-hd)-No. 10-32
x 3/8"-retain piston to rear servo
44713-S8
Washer (flat)-7/32" I. D. x 1/2" O. D.
