53-55 53-55 53-55 53-55 52-54 55  52-54 53-55   52-55 52-54 53-55  52-55  52-53 52-55 52-55 52-55 52-55 52-55  52-55 54-55 52-55 52-55 52-55
EAD 6507-N
Valve (intake)-Standard-use with EAD-6049-F head,
EAA-6571-C seal, EBU-6517-B sleeve and
EBU-6514-B Retainer for 1953-54
as
reqd
LA, LE
EAD 6507-R
Valve (intake)-. 003" O/S-use with EAD-6049-F
head, EAA-6571-C seal, EBU-6517-B sleeve and
EBU-6514-B retainer for 1953-54
as
reqd
LA, LE
EAD 6507-S
Valve (intake)-. 015" O/S-use with EAD-6049-F
head, EAA-6571-C seal, EBU-6517-B sleeve and
EBU-6514-B retainer for 1953-54
as
reqd
LA, LE
EAD 6507-T
Valve (intake)-. 030" O/S-use with EAD-6049-F
head, EAA-6571-C seal, EBU-6517-B sleeve and
EBU-6514-B retainer for 1953-54
as
LA, LE
EAD 6513-A
Spring (valve)-1" L D. x 2-7/32" long-7 coils
16
LA
EBB 6513-A
Spring (valve)
16
LE
EAD 6514-A
Retainer (valve spring)-1-11/32" O. D. x 37/64"
thick
16
LA
EBU 6514-B
Retainer (valve spring)
16
LA, LE
B3Q 6515-A
Spacer (valve spring)-. 030" thick- (DEAD-66514-A
as
reqd
LA, LE
EAA 6517-B
Sleeve (valve spring retainer)
16
LA
EBU 6517-B
Sleeve (valve spring retainer)
16
LA, LE
7HA 6518
Key (valve spring retainer)-11/32" L D. x 1/2" O. D.
x 3/8" thick
32
LA, LE
EAD 6519-A
Cover assembly (valve push rod)
LA
EAD 6519-B
Cover assembly (valve push rod)
1
LA, LE
352435-S
Bolt (hex-hd pointed)-5/16"-
18 x 4-5/8"-cover to cyl.
block
LA, LE
44724-S8
Washer (flat)-5/16"-cover to
cylinder block
LA, LE
EAD 6521-A
Gasket (valve push rod cover)-also serviced in
HEK-6608-D, HFK-6008-A, HCK-6079-D & E
& HFK-6079-A Kits
LA, LE
EAD 6524-C
Baffle (valve spring oil)-3-3/32" long
LA, LE
EAD 6531-A
Support (valve rocker arm shaft)-front
LA, LE
B4Q 6531-A
Support (valve rocker arm shaft)-front-
B4Q-6563-A Shaft must be used with this
support-'EAD-6531-B
LA, LE
354187-S
Bolt (hex head)-5/16"-18 ::
2-1/2"-rocker arm support
to cylinder heads
12
LA, LE
34806-S7
Lockwasher-5/16"-rocker arrm
support to cylinder heads
16
LA, LE
33798-S8
Nut (hex-hd)-5/16"-24-rocker
arm support to cyl. heads
4
LA, LE
354053-S
Stud-5/16"-18 & 5/16"-24 x
4-3/8"-rocker arm support
to cover & cylinder heads
LA
52-54
44722-S8
Washer (flat)-5/16"-rocker
arm support to cyl. heads
LA, LE
52-55
EAA 6549-B
Screw (valve rocker arm adjusting)-7/16"-20-with
ball end
LA, LE
52-55
EAA 6552-A
Nut (h x)-7/16"-20-valve adjusting
16
LA, LE
52-55
EAD 6563-B
Shaft (valve rocker arm)-17-19/32" long
LA
52-54
B4Q 6563-A
Shaft (valve rocker arm)-®EAD-6563-C
LA, LE
54-55
