LA 6028-B
Bracket assy engine front support)
LA, LE
52-55
357457-S
Bolt (hex-hd)-7/16"-14 x ' -
bracket to engine
LA, LE
52-55
34449-S8
Locknut (hex)-1/2"-20-bracket
to frame
LA, LE
52-55
357625-S7
Lockwasher-7/16" -bracket to
frame
LA, LE
52-55
44726-S8
Washer (flat)-3/8"-bracket to
frame
LA, LE
52-55
356474-S8
Washer (flat)-1/2" I. D. -
0. D. bracket to frame
LA, LE
52-55
LA 6038-A
Insulator assy (engine front support)-upper
LA
52-53
LA 6038-B
Insulator assy (engine front support)-upper
LA, LE
54-55
LA 6039-B
Insulator assy (engine front mount rebound)-lower
LA
52-54
LA 6039-C
I
lator assy (engine front mount rebound)-lower
LA, LE
52-55
EAD 6049-C
Head (cylinder)
LA
52
EAD 6049-D
Head (cylinder)
2
LA
53-54
EAD 6049-E
Head (cylinder)
2
LA
52
EAD 6049-F
Head (cylinder)
2
LA
53-54
EBJ 6049-E
Head (cylinder)
2
LE
55
N
87652-S8
Plug (tapered pipe thread)-
3/8"-18-used when hot
water heater is not used
replaced by 358066-S8
2
LA. LE
52-55
351798-S
Elbow-7/8"-18 tapped straight
thread x 3/8"-18 pipe male
thread-Brass
LA, LE
52-55
353063-S7
Plug (expansion)-1-1/4"
LA, LE
52-55
358066-S8
Plug (tapered pipe thread)-
3/8"-18-when hot water
heater is not used
LA, LE
52-55
356474-S18
Washer (flat)-1/2" I. D. x 1"
0. D. x 7/64" thick-cylinder
head bolts to cylinder block
use with EAD-6065-D and
EAD-6066-D
20
LA, LE
52-55
EAD 6051-A
S Gasket (cyl. head)-replaced by EAD-6051-B
LA
52
EAD 6051-B
Gasket (cyl, head)-also serviced in HEK-6008-D &
HCK-6079-D & E Kits
LA
52-54
EBJ 6051-C
Gasket (cyl. head)-also serviced in HFK-6008-A &
HFK-6079-A
LE
55
LA 6054-A
Plate assy (engine rear support)-5-23/64" long x
2" wide
LA, LE
52-55
20390-S8
Bolt (hex-hd)-7/16"-14 x "-
plate to transmission
LA, LE
52-55
34445 S8
Locknut (hex)-3/8"-24
LA, LE
52-55
34848-S8
Lockwasher-7/16"
2
LA, LE
52-55
44726-S8
Washer (flat)-3/8"
LA, LE
52-55
EAD 6059-A
Cover (cylinder front)-use with EAD-6010-D
LA
52-53
